Lanthanated MoLa Molybdenum Wire High Temperature Moly Wires Dia 0.05mm to 3.0mm
High Temperature Molybdenum Wire / MoLa Wire is for high temperature structural material (printing pins, nuts and screws), halogen lamp holders, Hi-Temp furnace heating elements and leads for quartz and Hi-Temp ceramic materials etc.
Molybdenum wire with 99.95% molybdenum is for single or double spiral cores, magnetron grids for lamps, locating rods and leading in pins, etc. Cutting Molybdenum Wire is for cutting machining for copper molds, hard-metal, magnetic materials, etc. with doped rare earth elements, suitable for high current (3A5A), high efficiency.
Characteristic of High Temperature Moly Wire:
Meeting the standard of GB4183-84. At the same environment and status, the using time could be improved to 100% or 200%.
Extend rate less 3%. The molybdenum wire could keep their good status.
The molybdenum wires are same size and lubricity on the face.
There are all kinds of molybdenum wire in our factory and they are good quality.
The molybdenum wires are packed at vacuum environment and could be kept more than 1 year.
Standard: through the ISO9001:2008 quality system certification
MoLa Wire Physical properties:
Melting point: 2625 degree.
Working temperature: 1700 degree.
Recrystallization: Starting temperature≥850degree.
Tensile strength≥800N/mm2.
Application of High Temperature Molybdenum Wires:
For redrawing.
For wire cutting.
For thermal spraying coating.
For electrical light source parts.
For high temperature components and heating elements.
Molybdenum Wire Types and Properties:
| Categories | Properties |
| High-strength Molybdneum wire | High tensile strength, high abrasion resistance, long life |
| Cold drawing Molybdneum wire | Apply cold drawing production technology, high-strength, smooth surface quality |
| Fixed length Molybdneum wire | In addition to the characteristics of high intensity Mo wire, there are advantages like fixed length, easy-to-use, high utilization rate |
| High-precision Molybdneum wire (special for medium speed wire cutting) | Add special element to ensure higher tensile strength, wear resistance and longer life. |
Moly Wire Specifications:
| Molybdenum Wire Types | Diameter (inch) | Tolerance (%) |
| Molybdenum Wire for EDM | 0.0024" ~ 0.01" | ±3% wt |
| Molybdenum Spray Wire | 1/16" ~ 1/8" | ±1% to 3% wt |
| Molybdenum Wire | 0.002" ~ 0.08" | ±3% wt |
| Molybdenum Wire(clean) | 0.006" ~ 0.04" | ±3% wt |
Composition of Pure Molybdenum:
| Grade | The impurity content is not more than % |
| Fe | Ni | Al | Si | Mg | C | N | O |
| Mo-1 | 0.01 | 0.005 | 0.002 | 0.01 | 0.005 | 0.01 | 0.003 | 0.008 |
| Mo-2 | 0.01 | 0.005 | 0.005 | 0.01 | 0.005 | 0.01 | 0.003 | 0.02 |
Products Show:
